Copper Alloy Leadframe
- Material: Copper
- Thickness: 0.5/0.6/0.7 mm
- Project Offer:Within 3 hours
- Process: Precision Etching
- Custom Cycle:Involving Mold Opening, – monthly sample delivery
- Production Capacity:5000-10000PCS/day
- Application: Semiconductor Packaging
- Add Process:Stamping, Self-Owned Hardware Mold Room, Electroplating, Electrophoresis, PVD Vacuum Plating
- Type: Kovar Etching
High-Quality Precision Etched Copper Alloy Leadframe
Copper alloy leadframes are an essential component in many electronic devices, particularly in semiconductor packages and integrated circuits (ICs). They serve as the physical structure that connects the IC chip to the outside world, providing electrical connections and support for the chip.
Leadframes contain a pattern of thin copper alloy leads that connect the IC chip to the external pins or contacts. These leads facilitate the transmission of electrical signals between the chip and the rest of the device.
Copper alloy leadframes are typically made from a combination of copper and other alloying elements. These alloys are chosen for their electrical conductivity, thermal conductivity, and mechanical properties. Common alloys used for leadframes include copper alloys with additives like nickel, iron, and manganese.
Why Choose Our Precision Etched Copper Alloy Leadframe Service?
- Etching processing technology is adopted, with high precision, up to ±0.008mm (different thickness of different materials). 15 years of professional precision etching processing factory, the quality is trustworthy.
- The etching process of Be-cu has no restrictions on complex patterns and arbitrary geometric figures. No matter how complicated the hole shape or pattern is, it can be formed in one process without increasing the production cost.
- Be-cu chemical etching is a double-sided simultaneous processing technology. The surface of the product (front and back) is smooth, no bumps, no pits, no burrs, no warping, the mesh is flat and no deformation, no need to polish , Polishing, self-care process after flattening.
- The size of etching process is fine (aperture ≥ 0.1mm, thickness 0.03-2.0mm), and the positioning is accurate (minimum precision ± 0.008) uniform.
- The production cycle is short, the response is fast, and the design is easy to modify. The Be-cu professional etching technology engineering team has a total of 17 people and has senior technicians who have been in the industry for 15+ years.
- Be-cu samples are produced quickly, and samples can be produced within 1-2 working days (determined according to product requirements).
- Be-cu etching has 16 automatic etching production lines, with high etching processing output, which can meet your production orders for batch processing and etching customized microporous mesh.
- Be-cu provides auxiliary services such as stamping, welding, oil spraying, painting, electrophoresis, electroplating, electrolysis, passivation, polishing, stretching, wire drawing, silk screen LOGO, injection molding, etc., to meet the needs of different products and realize convenient and fast — One-stop processing service.
- Be-cu has passed the factory inspections of many well-known companies such as Gree, Joyoung, Xinbao, Xiaomi, Lake and American and German customers. The quality and delivery time are stable, and the customer satisfaction and employee satisfaction are high.
Contact Be Cu Now for your Custom Metal Etching, We are your best online Etching services choice!
Specifications of Precision Etched Copper Alloy Leadframe
| Material Type | Aluminium/Brass/Copper/Nitinol/Stainless steel/Titanium |
| Size | Customized |
| Min. Hole Dia. | Dia.≥1.2xT |
| Min. Pitch | D≥1.0xT |
| Tolerance | 0.003mm |
| Material Thickness | T≥0.03mm |
| Process | Etching/Plating/Stamping/Bending/Laser cuting |
| Surface Finish | PVD/Coating/Painting |
| Inspection | IPQC/AQL |
| Packing | Plastic Tray or Customized |
