SOP Lead Frame
- Material: Kovar alloy
- Thickness: 0.5/0.6/0.7 mm
- Project Offer:Within 3 hours
- Process: Precision Etching
- Custom Cycle:Involving Mold Opening, – monthly sample delivery
- Production Capacity:5000-10000PCS/day
- Application: Semiconductor Packaging
- Add Process:Stamping, Self-Owned Hardware Mold Room, Electroplating, Electrophoresis, PVD Vacuum Plating
- Type: Kovar Etching
High-Quality Precision Etched SOP Lead Frame
Are you looking for superior semiconductor packaging leadframe solutions? Stop looking any further. We specialize in precision etching high quality lead frames using premium materials such as copper, copper alloys and iron-nickel alloys. Our versatile leadframes are designed to meet the needs of various semiconductor packaging formats, including DIP (Dual In-line Package) and QFP (Quad Flat Package).
Key Features:
- PRECISION MANUFACTURING: Our leadframes are precision engineered to ensure a perfect fit and provide optimal performance for your semiconductor application.
- High Conductivity: Achieve superior electrical conductivity to enhance electrical connections within semiconductor devices.
- Customization Options: We offer customizable lead frames to meet your specific needs and project requirements.
- Fast Delivery: Our lead frames can be delivered within 7 to 15 days, ensuring your project stays on schedule.
- Multiple material options: Depending on the unique needs of your project, you can choose from a variety of materials, including copper, copper alloys, iron-nickel alloys, and more.
Application areas:
Our leadframes are ideally suited for a variety of semiconductor applications, including but not limited to:
- integrated circuit (IC)
- transistor
- diode
- microcontroller
- sensor
- contact us:
When it comes to semiconductor packaging lead frames, we’re here to help. Contact us today to discuss your specific needs and find out how our high-quality lead frames can help with your project. We’re here to provide you with precise solutions.
Why Choose Our Precision Etched SOP Lead Frame Service?
- Etching processing technology is adopted, with high precision, up to ±0.008mm (different thickness of different materials). 15 years of professional precision etching processing factory, the quality is trustworthy.
- The etching process of Be-cu has no restrictions on complex patterns and arbitrary geometric figures. No matter how complicated the hole shape or pattern is, it can be formed in one process without increasing the production cost.
- Be-cu chemical etching is a double-sided simultaneous processing technology. The surface of the product (front and back) is smooth, no bumps, no pits, no burrs, no warping, the mesh is flat and no deformation, no need to polish , Polishing, self-care process after flattening.
- The size of etching process is fine (aperture ≥ 0.1mm, thickness 0.03-2.0mm), and the positioning is accurate (minimum precision ± 0.008) uniform.
- The production cycle is short, the response is fast, and the design is easy to modify. The Be-cu professional etching technology engineering team has a total of 17 people and has senior technicians who have been in the industry for 15+ years.
- Be-cu samples are produced quickly, and samples can be produced within 1-2 working days (determined according to product requirements).
- Be-cu etching has 16 automatic etching production lines, with high etching processing output, which can meet your production orders for batch processing and etching customized microporous mesh.
- Be-cu provides auxiliary services such as stamping, welding, oil spraying, painting, electrophoresis, electroplating, electrolysis, passivation, polishing, stretching, wire drawing, silk screen LOGO, injection molding, etc., to meet the needs of different products and realize convenient and fast — One-stop processing service.
- Be-cu has passed the factory inspections of many well-known companies such as Gree, Joyoung, Xinbao, Xiaomi, Lake and American and German customers. The quality and delivery time are stable, and the customer satisfaction and employee satisfaction are high.
Contact Be Cu Now for your Custom Metal Etching, We are your best online Etching services choice!
Specifications of Precision Etched SOP Lead Frame
Material Type | Aluminium/Brass/Copper/Nitinol/Stainless steel/Titanium |
Size | Customized |
Min. Hole Dia. | Dia.≥1.2xT |
Min. Pitch | D≥1.0xT |
Tolerance | 0.003mm |
Material Thickness | T≥0.03mm |
Process | Etching/Plating/Stamping/Bending/Laser cuting |
Surface Finish | PVD/Coating/Painting |
Inspection | IPQC/AQL |
Packing | Plastic Tray or Customized |
